Description
Technical Data (Order Number 0572 1753)
Temperature Measurement Specifications
| Sensor: | T/C (Thermocouple types T and K) |
| Channels: | 2 x external |
| Measurement Units: | °C, °F |
| Measuring Range (Type T): | -50 to +400°C |
| Measuring Range (Type K): | -50 to +1000°C |
| Resolution: | 0.1°C |
| Accuracy (±1 digit, -50 to +70°C): | ±0.5°C |
| Accuracy (±1 digit, +70.1 to +1000°C): | ±0.7% of meas. val. |
General Technical Data and Memory
| Dimensions: | 89 x 53 x 27 mm |
| Operating Temperature: | -20 to +55°C |
| Storage Temperature: | -20 to +55°C |
| Protection Class: | IP 65 |
| Battery Type: | 3 × AAA alkaline manganese or Energizer |
| Battery Life (at +25°C): | 3 years (with 15 min. measuring cycle) |
| Measurement Frequency: | 10 s – 24 h |
| Memory: | 1 million values |
